Epoxy Coated Wire Mesh

Epoxy coating is relatively low in cost, resilient, corrosion resistant, and has good insulating properties. Tianjia carries Epoxy coated wire mesh in a variety of materials including carbon steel and aluminum....

Send Email

Epoxy coating is relatively low in cost, resilient, corrosion resistant, and has good insulating properties. Tianjia carries Epoxy coated wire mesh in a variety of materials including carbon steel and aluminum.

Benefits of Epoxy Coated Wire Mesh:

- Intensive use without stripping or peeling.

- Will last many years longer than an uncoated wire.

- Available in many colors: charcoal, gray.

- Customer colors are available.

- Prevents corrosion.

Technical Data:

Material: Anaerobic annealing low carbon steel wire or aluminum alloy wire. It is fixed by anti-corrosion by epoxy powder coating.

Mesh (ends/in):

- Warp: 18 +/-1

- Fill: 16 +/-1

Diameter (inch): .009 - .010

Width (inch): 24 - 48

Max. Length (Linear Feet): 1200

Weight (oz/yd sq): 4.80

Tensile Strength (ksi): 52

Fabric Thickness (in.): .021 - .025

Elongation (%): 5%

Openness (%): 68%

Roll Core Diameter (in.): 3

Applications: Air filter

Weaving type: Plain

Performance: Acid, alkali, low temperature, waterproof, antistatic, others.

Scope of application: Car launch system, filter pot, air purifier, filter, others.
