Razor Wire
Material: Hot-dipped Galvanized razor wire or stainless steel, inside wire is hot-dipped high carbon steel wire. Razor wire can be installed in the form of barbed tape wire or concertina coil to walls or fencings....
Material: Hot-dipped Galvanized razor wire or stainless steel, inside wire is hot-dipped high carbon steel wire.
Razor wire can be installed in the form of barbed tape wire or concertina coil to walls or fencings.
Type of razor wire:
·Straight Type
·Concertina Single Type
·Concertina Cross Type
·Flat Type
·Welded Type
Blade Specification | Blade Type | Blade Thickness | Core Wire Dia. | Blade Length | Blade Width | Blade Space |
BTO-10 |
| 0.5±0.05 | 2.5±0.1 | 10±1 | 13±1 | 26±1 |
BTO-12 |
| 0.5±0.05 | 2.5±0.1 | 12±1 | 15±1 | 26±1 |
BTO-18 |
| 0.5±0.05 | 2.5±0.1 | 18±1 | 15±1 | 33±1 |
BTO-22 |
| 0.5±0.05 | 2.5±0.1 | 22±1 | 15±1 | 34±1 |
BTO-28 |
| 0.5±0.05 | 2.5 | 28 | 15 | 45±1 |
BTO-30 |
| 0.5±0.05 | 2.5 | 30 | 18 | 45±1 |
CBT-60 |
| 0.6±0.05 | 2.5±0.1 | 60±2 | 32±1 | 100±2 |
CBT-65 |
| 0.6±0.05 | 2.5±0.1 | 65±2 | 21±1 | 100±2 |
Outside Dia | No. of Loops | Standard Covering Length | Production Model | Remarks |
450mm | 33 | 8M | CBT-65 | Single coil |
500mm | 41 | 10M | CBT-65 | Single coil |
700mm | 41 | 10M | CBT-65 | Single coil |
960mm | 53 | 13M | CBT-65 | Single coil |
500mm | 102 | 16M | BTO-12.18.22 | Cross type |
600mm | 86 | 14M | BTO-12.18.22 | Cross type |
700mm | 72 | 12M | BTO-12.18.22 | Cross type |
800mm | 64 | 10M | BTO-12.18.22 | Cross type |
960mm | 52 | 9M | BTO-12.18.22 | Cross type |
